Overview

The 3D UV Curing Machine (also known as Stereoscopic UV Curing Equipment) is a specialized industrial curing system designed for three-dimensional workpieces. Unlike conventional flatbed UV machines that only cure planar surfaces, this equipment features multi-directional UV lamp arrangements (side lamps + top lamp) to deliver uniform ultraviolet exposure to the top and sides of 3D objects simultaneously. It is widely used in printing, coating, and adhesive curing processes for irregularly shaped products such as cosmetic bottles, thermos cups, helmets, automotive parts, and plastic products.

Key Features

• Multi-Directional Curing – Equipped with side lamps and top UV lamps (wavelength: 365nm), the system enables simultaneous curing of multiple surfaces of three-dimensional workpieces, ensuring thorough and uniform polymerization.

• Adjustable UV Intensity – Features stepless dimming electronic power supplies with built-in lamp timing, allowing precise control of UV output to match different coating and ink formulations.

• Efficient Cooling System – Utilizes a 750W centrifugal exhaust fan at the top to extract heat from lamp housings in 3 directions, supplemented by side fans for optimal thermal management and extended lamp life.

• Reliable Conveying System – Equipped with stainless steel chain plate conveyor or Teflon mesh belt (up to 890mm wide), driven by a 250W variable-speed motor with electronic speed controller for smooth and adjustable conveying (3–12 m/min).

• Robust Construction – Built with SS41# cold-rolled steel and galvanized plates, finished with anti-rust treatment and electrostatic high-temperature powder coating (wrinkle gray-white). Curing chamber features removable side doors for easy maintenance and cleaning.

• Comprehensive Safety Protection – Includes leakage circuit breaker, phase reversal protector, over-temperature alarm, motor and heater over-current protection, meeting international safety standards. All exposed electrical parts are covered with insulated protective guards, with hazard warning labels. Electrical enclosure rated IP54.

• User-Friendly Design – Bottom-mounted heavy-duty 3-inch casters with M18 leveling feet (±50mm adjustable height) for easy positioning and installation.

Technical Specifications (Reference Model)

Applications

The 3D UV Curing Machine is ideal for curing UV-curable inks, coatings, and adhesives on three-dimensional substrates across various industries:

• Cosmetics & Packaging – Cosmetic bottles, perfume containers, decorative packaging

• Household Products – Thermos cups, insulated drinkware

• Automotive – Helmets, interior trim parts, automotive accessories

• Plastics & Electronics – Plastic housings, electronic components, 3D printed parts

• Furniture & Building Materials – Wooden panels, solid wood doors, cabinet doors, office furniture, aluminum-plastic panels, glass, marble, stainless steel

Customization & After-Sales Service

• Customization – Non-standard sizes and configurations available upon request to meet specific production requirements

• Warranty – 1-year warranty from delivery date (lamp bulbs guaranteed for 1,000 hours)

• Training – Free training on programming, operation, troubleshooting, and daily maintenance

• Technical Support – Free ongoing technical consultation and fault handling services
