Product Features
Suitable for sanding after priming of panel furniture, engineered wood flooring, flat doors, handicrafts, bamboo‑wood curtains and other flat‑shaped workpieces.
The machine features a heavy‑duty frame with heat‑treated components for high structural strength and stable operation. Key components adopt well‑known brand parts sourced from the USA, Japan and Taiwan, delivering high precision and long service life. Computer‑controlled fixed‑thickness sanding enables more accurate and convenient thickness adjustment.
The rubber roller is made of imported wear‑resistant natural rubber with hardness of 20‑40 Shore A. Variable‑frequency adjustable sanding‑belt speed adapts to various paint properties and effectively eliminates cross‑stripes and white‑edge defects.
The workpiece feeding system adopts a pressure‑shoe and press‑roller structure, which supports processing of boards with relatively large surface deformation.
The frame is constructed from bent and welded steel plates, ensuring heavy weight and smooth running performance.
Four‑post lifting mechanism is applied for worktable elevation, which guarantees low positioning error and high machining precision.
The polishing roller unit can effectively remove sanding marks and greatly improve the final surface quality after top‑coat painting.
Technical Parameters
| Model |
600 |
910 |
1300 |
| Working Width |
610 mm |
910 mm |
1310 mm |
| Working Thickness |
2‑80 mm |
2‑80 mm |
2‑80 mm |
| Minimum Working Length |
300 mm |
300 mm |
300 mm |
| Feeding Speed |
5‑20 m/min |
5‑20 m/min |
5‑20 m/min |
| Feeding Power |
0.75 kW |
0.75 kW |
1.5 kW |
| Lifting Power |
0.37 kW |
0.37 kW |
0.37 kW |
| Brush Power |
0.37 kW |
0.37 kW |
0.37 kW |
Technical Parameters
| Model |
600 |
910 |
1300 |
| Air Outlet Diameter |
100 mm |
160 mm |
160 mm |
| Air Pressure |
3‑6 kg |
3‑6 kg |
3‑6 kg |
| Polishing Roller Power |
1.5 kW |
1.5 kW |
1.5 kW |
| Overall Dimensions (L×W×H) |
1600×1480×1750 mm |
1600×1750×1750 mm |
1600×2150×1750 mm |
| Total Power |
9.8 kW |
12.0 kW |
16.0 kW |
| Machine Weight |
900 kg |
1100 kg |
1500 kg |
